Fan motor
DC MOTOR
NO.
|
MOLD NO.
|
ROTATION
|
FAN SIZE
|
RATED
|
RPM
|
CURRENT(A)
|
INPUT(W)
|
SHAFT(L)
|
ITEM6
|
ITEM19
|
1
|
11
|
CCW
|
Φ150 3-WING
|
DC
|
1550±150
|
0.192±20%
|
2.3±20%
|
40
|
B
|
B
|
2
|
12
|
CCW
|
Φ95 4-WING
|
DC
|
2520±150
|
0.150±20%
|
1.8±20%
|
48.8
|
C
|
B
|
3
|
13
|
CCW
|
Φ100 4-WING
|
DC
|
2950±150
|
0.208±20%
|
2.5±20%
|
40
|
B
|
B
|
|
4
|
39
|
CCW
|
Φ130.5 3-WING
|
DC
|
2280±8%
|
0.470±20%
|
5.72±20%
|
48
|
A
|
A
|
|
5
|
63
|
CCW
|
Φ120 11-WING
|
DC
|
2460±9%
|
0.505±20%
|
6.06±20%
|
48
|
A
|
A
|
|
NO.
|
PART NAME
|
SPEC
|
MOLD NO.
|
REMARK
|
|
1
|
RESIN
|
-
|
BMC MOLDING
|
ALL
|
|
|
2
|
STATOR ASS'Y
|
-
|
S-60,Φ58,T5
|
39 63
|
6SLOT
|
|
3
|
INSULATOR A
|
-
|
NYLON #66
|
39 63
|
6SLOT
|
|
4
|
INSULATOR B
|
-
|
NYLON #66
|
39 63
|
6SLOT
|
|
5
|
MAGNET WIRE
|
-
|
UEW
|
39 63
|
|
|
6
|
ROTOR ASS'Y
|
A
|
OD30,L74.8
|
39 63
|
|
|
B
|
OD29.85,L66.3
|
11 13
|
|
|
C
|
OD29.85,L75
|
12
|
|
|
7
|
MAGNET
|
|
8POLE
|
ALL
|
PLASTIC FERRITE
|
|
8
|
SHAFT ROTOR
|
|
SUS420J2
|
39 63
|
|
|
9
|
FELT COVER
|
|
SCP2
|
39 63
|
|
|
10
|
PIECE STAY
|
|
NYLON #66
|
39 63
|
|
|
11
|
BEARING-OILLESS
|
A
|
Cu+Fe Serise
|
39
|
|
|
B
|
Cu Serise
|
63
|
|
12
|
OIL
|
A
|
（PW280）
|
39
|
0.5±0.1g
|
|
B
|
(CP4617-5F)
|
63
|
0.5±0.1g
|
13
|
COVER-BEARING
|
A
|
SCP2
|
39
|
|
|
B
|
SECD(Cr3+)
|
63
|
|
|
14
|
FELT
|
A
|
WOOL
|
39 63
|
|
15
|
PCB ASS'Y
|
A
|
BA6425
|
39 63
|
6SLOT 3PIN
|
|
16
|
WAFER
|
-
|
-
|
39 63
|
|
19
|
OIL CUTTER
|
-
|
POLY WASHER
|
ALL
|
|
|
20
|
OIL CUTTER
|
-
|
POLY WASHER
|
ALL
|
|
21
|
MARAING
|
-
|
STAMP
|
39 63
|
|
|
-
|
30*15
|
11
|
PINK+SILVER
|
|
-
|
30*15
|
12
|
BROWN+SILVER
|
|
-
|
30*15
|
13
|
SKY BLUE+SILVER
|
|
22
|
MARAING
|
-
|
LASER
|
39 63
|
|
|
23
|
HALL SENSER HOLDER
|
-
|
NYLON #66
|
39 63
|
|
AC motor
NO.
|
MOLD NO.
|
FAN SIZE
|
ROTATION
|
Voltage / frequency
|
RPM
|
CURRENT (A)
|
INPUT (W)
|
No load starting
|
No load noise
|
|
1
|
YJF61/10
|
φ100 4-WING
|
CCW
|
AC230V 50Hz
|
2450±150r/min
|
0.050±10％A
|
6.5±10％W
|
≤172V
|
≤ 38dB
|
|
NO.
|
MOLD NO.
|
FAN SIZE
|
ROTATION
|
Voltage / frequency
|
RPM (r/ min)
|
CURRENT (A)
|
INPUT (W)
|
|
1
|
5210000
|
φ3.17×Φ100×4
|
CCW
|
AC220V 50Hz
|
2650±150
|
0.059±10％A
|
7.0±10％W
|
|
NO.
|
MOLD NO.
|
FAN SIZE
|
ROTATION
|
Voltage / frequency
|
RPM (r/ min)
|
CURRENT (A)
|
INPUT (W)
|
|
1
|
52200003
|
φ3.17×Φ100×4
|
CW
|
AC220V 50Hz
|
2650±150
|
0.059±10％A
|
7.0±10％W
|
